PF Sereis Impact Crusher
Product Description
Applicabilities
With high crushing ratio,simple and appropriate structure and high crushing efficiency,these crushers maintain steady operations and are easy to maintain.It is expedient to replace the parts.Widely applied in sectors of building materials,mineral processing,chemical engineering and electric power,these crushers are mainly used for crushing materials with medium degree of hardness.
Working Principle
The impact crushers crush materials with high-speed impact.When materials enter the acting zone of the plate hammer through the feed port,they will be subject to high-speed impact of the hammer and crushed for the first time.The powerful impact force casts the materials to the impact plate,and the materials are crushed again.The materials sprung back from the impact plate fall upon the acting zone of the plate hammer.Then the above steps are repeated until the particle size of the crushed materials is smaller than the diameter of the discharge port.The crushed materials are subsequently discharged through the discharge port dependent upon their dead weight by adjusting the spacing between the impact bracket and the rotor,the particle size and shape of the discharged materials may be changed.
Product Features
High Crushing Ratio
With high crushing ratio,simple and appropriate structure and high crushing efficiency,these crushers maintain steady operations and are easy to maintain.
It is expedient to replace the parts.Widely applied in sectors of building materials,mineral processing,chemical engineering and electric power,these crushers are mainly used for crushing materials with medium degree of hardness and britle materials.
Higher Production Efficiency
The optimized crushing chamber accepts materials with bigger feed particle size.The optimized liner and specific rotor greatly increase production efficiency under different conditions.
Durable And Reliable
The plate hammer,impact liner and wear parts inside the chamber are made of high chromium and manganese materials,which make wear parts(e.g.plate hammer and impact hammer)more durable and mechanical parts of the crusher(including spindie and bearings)more reliable.
Convenient Overhaul
The crusher may be configured for hydraulic uncovering,to make it convenient to disassemble and replace wear parts.
Technical Specifications
| Model | Linear Speed (m/s) | Motor Power (kw) | Treatment Capacity (t/h) | Feed particle Size (mm) | Standard Motor Power(kw) | Maintreme Wei (excuding motor)(kg) |
| PF1315 | 45 | 200-250 | 150-300 | <400 | 250 | 18000 |
| PF1520 | 39 | 2X200 | 400-500 | <700 | 2X250 | 34800 |
| 2X250 | ||||||
| 2X280 | ||||||
| 2X315 | ||||||
| PF1524 | 39 | 2X280 | 500-600 | <700 | 2X315 | 41800 |
| 2X315 | ||||||
| 2X355 | ||||||
| PF1823 | 37 | 800-1000 | 600-850 | <800 | 800 | 64900 |
| PF2124 | 37 | 2X560 | 800-1530 | <1200 | 2X710 | 109456 |
| 2X710 |
The PF Series Impact Crusher is an efficient crushing machine designed for medium and fine crushing applications in mining, construction, aggregate production, and recycling industries. As an important part of an advanced Industrial Crushing Solution, this equipment is engineered to deliver high crushing efficiency, stable operation, and consistent output quality. Featuring a strong structural design, optimized crushing chamber, and durable wear-resistant components, the PF Series Impact Crusher can effectively process various materials while reducing maintenance requirements. Its adjustable discharge opening allows users to control final product size according to different production needs, improving processing flexibility. The machine adopts reliable transmission components and a balanced rotor system to ensure smooth operation and excellent impact performance. During manufacturing, strict quality control is applied through precision component processing, assembly inspection, and performance testing to guarantee long-term durability. With its combination of efficient crushing capability, easy maintenance, and practical design, the PF Series Impact Crusher provides a dependable choice for industries seeking stable and economical crushing solutions.
